Here is my article on the walkthrough of a free room: Memory Analysis Introduction ↗. Learn how memory analysis helps detect threats during live investigations. I wrote this in 2025 and hope it is useful for learning about memory analysis.

Task 1: Introduction#

This session explores how memory analysis supports cyber security investigations, focusing on volatile memory and its role in identifying threats, user activity, and attack traces. It covers memory dumps, attack fingerprints, and their use in real-world cases, with interactive sections to visualize memory structures.

Objectives:

Understand memory analysis in cyber security.
Identify memory structure and behavior.
Recognize attack traces in memory.

Prerequisites:

No answer needed

Task 2: Volatile Memory#

Volatile memory, primarily RAM. Once the system is turned off, this data is lost, making it a priority to capture RAM early during investigations.

Memory Hierarchy:

CPU Registers & Cache: Fast but limited in size.
RAM: Main memory for active programs and the operating system.
Disk Storage: Slow, used for long-term storage.
Virtual Memory: Maps virtual addresses to RAM or swap space on the disk when physical memory is full.

RAM is structured into kernel space (for OS and low-level services) and user space (for user processes), with specific regions for:

Stack: Stores temporary data like function arguments.
Heap: For dynamic memory allocation during runtime.
Executable (.text): Stores the CPU instructions.
Data sections: Stores global variables.

Memory analysis offers insights into live system activity, including:

Running processes
Open network connections
Logged-in users and recent commands
Injected code or fileless malware

Since this data disappears after shutdown, memory forensics helps collect vital information during live system investigations.

Q1: What type of memory is prioritized because its data disappears after shutdown?

RAM

Q2: What is the slowest component in the memory hierarchy?

disk

Q3: Which memory region typically contains dynamically allocated data like encryption keys?

heap

Q4: What disk-based area temporarily stores RAM data when memory is full?

swap

Task 3: Memory Dumps#

A memory dump is a snapshot of a system’s RAM at a specific moment, capturing data like running processes, network activity, and potentially sensitive information. It plays a key role in forensic analysis, malware investigations, and threat hunting. Security teams analyze memory dumps to detect unauthorized activities, while tools like Mimikatz are used to extract credentials, making memory dumps critical for defense.

Memory dumps can be created using various tools depending on the OS:

Windows: WinPmem, Sysinternals RAMMap, or built-in crash dumps.
Linux/macOS: LiME, dd, or accessing /dev/mem.

There are different types of memory dumps:

Full Memory Dump: Captures all RAM, including user and kernel space.
Process Dump: Captures memory of a single process.
Pagefile/Swap Analysis: Analyzes memory swapped to disk.

Challenges in acquiring a clean memory dump include anti-forensic techniques like hidden modules, kernel manipulation, code injection, and encrypted payloads. These require advanced methods such as memory carving and kernel-level inspection to uncover hidden activities.

Q1: What tool is commonly used by attackers to extract credentials from memory?

Mimikatz

Q2: What type of memory dump captures all RAM, including user and kernel space?

full

Q3: What Linux tool can be used to extract memory for forensic purposes?

lime

Q4: Which file on Windows systems stores memory during hibernation?

hiberfil.sys

Q5: What anti-forensics technique hides processes by altering kernel structures?

DKOM

Task 4: Memory Analysis Attack Fingerprints#

Memory analysis is critical for identifying active, fileless attacks that evade disk-based forensics. Key indicators include:

Common Artifacts:#

Suspicious processes/DLLs (no disk file).
Process hollowing, API hooking, kernel rootkits.
Anomalies like mismatched PE headers or code in writable memory.

Credential Access (T1003):#

In-memory extraction of credentials (e.g., LSASS dumping) and C2 communications via HTTP/DNS (decrypted configs/beacons visible in memory).

In-Memory Scripts (T1086):#

Malicious PowerShell/Python scripts executed in RAM, leaving encoded commands or runtime traces.

Persistence Mechanisms:#

Scheduled Tasks (T1053.005): Malicious schtasks.exe arguments.
Services (T1543.003): Unusual service binaries in services.exe.
Registry Run Keys (T1547.001): Malware paths in memory-cached registry hives.

Lateral Movement:#

PsExec (T1021.002): Service creation/command-line args.
WinRM/PowerShell (T1021.006, T1059.001): Remoting artifacts, base64-encoded commands.
WMI (T1047): Suspicious wmic process-creation strings.

Memory forensics tools (e.g., Volatility) uncover these stealthy tactics by analyzing runtime artifacts and kernel structures.

Q1: What technique involves replacing a trusted process’s memory with malicious code?

Process hollowing

Q2: Which Windows service provides PowerShell remoting?

WinRM

Q3: What MITRE technique ID is associated with in-memory PowerShell execution?

T1086

Q4: What command-line tool enables remote execution and is linked to lateral movement (T1021.002)?

PsExec

Q5: Which MITRE technique involves setting tasks that persist through reboots (e.g., schtasks.exe)?

T1053.005

Task 5: Practical#

Visit the site below, place the term in the proper definition, and get the flag.

Interactive Exercise ↗

You can follow the answer below to complete it and get the flag.

Main working memory in an OS

RAM

Contains processes launched by the user or applications

User-Space

PsExec enables command execution on remote systems

T1021.002 — Remote Services

Stores temporary data like function arguments and return addresses

Stack

Captures all RAM, including user and kernel space

Full Memory Dump

Malicious code is injected into legitimate processes

Code Injection

“Before I finish, I apologize for blurring the flag. I wanted you to experience taking action, not just answering the question. Thank you.”

Q1: What is the value of the flag?

THM(******_******_****_***)

Task 6: Conclusion#

In this room, we learned the significance of memory analysis in digital forensics, focusing on volatile memory, RAM’s role in storing active data, and its priority during incident response. We explored memory structure, forensic artifacts, and the creation of memory dumps. Additionally, we examined common attack techniques like credential dumping, DLL injection, script execution, and persistence or lateral movement, highlighting RAM’s crucial role in threat detection.

No Answer Needed
